[ 2D WIRED BARCODE SCANNER ]

DC7121 – 2D WIRED BARCODE SCANNER

New ABS Design: Ergonomically designed for durability and comfortable usage.
Can Read Barcodes as Small as 4 Mil: Offers precise scanning for tiny barcodes.
Easily Reads Poor Quality & Mobile Barcodes: Ensures reliable performance even with challenging barcode conditions.
32-Bit CPU: Delivers exceptional decoding speed and accuracy.

SKU: DC7121

Availability: In stock

Call +91 9250910221

Whatsapp Us

Product Overview

This 2D Wired Barcode Scanner is engineered to deliver superior performance for scanning barcodes with precision. It efficiently reads both 1D and 2D barcodes, including poor-quality or mobile screen barcodes, making it suitable for a wide range of applications. Its robust ABS design ensures comfort and long-lasting use, while its wired connectivity guarantees stable performance.

Efficient Features

• High Decoding Ability: Powered by a 32-bit ARM Cortex CPU, it quickly decodes barcodes, including low-quality or damaged ones.

• Wide Scanning Range: Reads barcodes from a distance of 5cm to 30cm, ensuring flexibility in usage.

• High Resolution: Capable of reading barcodes as small as 4 mil for detailed and precise data capture.

• User-Friendly Indicators: Equipped with buzzer and LED prompts for easy operation and feedback.

• Sleek and Durable Design: Constructed with high-quality ABS material for ergonomic and long-term use.

Performance

• Fast Scanning: Delivers a scanning speed of up to 500 scans per second, ensuring quick and accurate data capture in high-volume environments.

• Exceptional Contrast Reading: Reads barcodes with print contrast as low as 20%, making it effective even in challenging conditions.

• Broad Light Immunity: Performs efficiently under varying lighting conditions from 0 to 100,000 Lux.

• Low Error Rate: Offers a remarkable error rate of less than 1 in 5 million scans for reliable performance.

Compatibility

The device supports a wide range of barcode types, including 1D barcodes such as UPC-A, UPC-E, EAN-13, EAN-8, Code 39, Code 128, Codabar, and more, as well as 2D barcodes like QR Code, PDF417, Data Matrix, Aztec, MaxiCode, and others. It is versatile and suitable for use across various industries, including retail, logistics, healthcare, jewelry, and warehouses. With its plug-and-play design, the device offers easy integration through a wired USB connection, ensuring compatibility with different systems without the need for additional setup.

Reliability

The device features a durable build, constructed with premium ABS material that is capable of withstanding daily usage and harsh conditions. It is designed to endure accidental drops, ensuring uninterrupted functionality even in tough environments. The device operates seamlessly in temperatures ranging from 0°C to 50°C and can be stored in conditions between -30°C and 70°C. Additionally, it functions reliably in humidity levels between 5% and 95% (non-condensing). For added peace of mind, it comes with an extended 24-month warranty against manufacturing defects, ensuring long-term reliability and customer satisfaction.

SKU: DC7121
/
Category: 2D WIRED BARCODE SCANNER

Technical Specifications

Scan Type	Area Imager
Lighting Aimer	CMOS 640 x 480
Scan Width	5cm to 30cm
Scanning Speed	500 per second
Scan Angle	Rotation 30° / Incline +55° / Decline +60°
Resolution	4 mil
CPU	ARM 32 bit Cortex
Print Contrast	220%
Error Rate	<1/5 million
Prompt Mode	Buzzer, LED
Decoding Capability	1D: UPC-A, UPC-E, Code128, EAN-13, EAN-8, ISBN, Code 93, UCC/EAN-128, GS1 Code39, Code 39 Full ASCII, Codabar, Interleaved 2 of 5, Databar, MSI, Code11, ISBN, ISSN, China Post, etc. 2D: QR code, PDF 417, Data Matrix, Aztec, Maxicode, etc.
Electric Voltage	5V DC
Current	Work: 86mA, Standby: 42mA, Starting: 130mA
Ambient Light Immunity	0-100,000 Lux
Dimensions	170mm x 92mm x 55mm
Weight	435g
Working Temperature	-0°C ~ 50°C
Storage Temperature	-30°C ~ 70°C
Humidity	5% to 95% Relative Humidity, Non Condensing
Drop Test	2m
Warranty	24 Months against any manufacturing defect
